OWOX Data Marts

How to Contribute

There are thousands of data sources and their APIs constantly evolve, so no single team can build and maintain every connector. Within the OWOX Data Marts project we collaborate as a community to share this responsibility, and this guide explains how you can work with us to adjust existing integrations and create new ones.

When contributing, please keep the wider community in mind. We review pull requests for technical quality and for how broadly the connector can be applied beyond the contributor’s specific scenario. If you plan work that cannot be contributed back, be ready to maintain your own fork. We highly recommend designing every connector so that it can be upstreamed when requirements allow.

Prerequisites

Section titled “Prerequisites”

Set up the following tools locally before you start developing:

  • Node.js 22.16.0 or later (see engines.node requirement in root package.json)
  • npm 10 or later (ships with the Node 22 installer)
  • Git (any recent 2.x release) for working with the repository

After installing the tools, run npm install from the repository root to install all workspace dependencies, including those needed for this package.

Architecture Overview

Section titled “Architecture Overview”

The @owox/connectors package is a Node.js library that bundles data source connectors and storage implementations. The package automatically discovers all connectors in the src/Sources/ directory.

Key Components

Section titled “Key Components”
  • Core (src/Core/) — Abstract base classes and utilities shared across all connectors (TypeScript/JavaScript)
  • Sources (src/Sources/[SOURCE_NAME]/) — Data source-specific implementations
  • Storages (src/Storages/) — Storage implementations for persisting data
  • Constants (src/Constants/) — Shared constants and enumerations
  • Configs (src/Configs/) — Configuration utilities

Build System

Section titled “Build System”

The build system automatically:

  1. Discovers all connectors in src/Sources/*/
  2. Bundles each connector with its dependencies into isolated modules
  3. Generates a single distributable package with all connectors
  4. Creates manifests with metadata for each connector

No manual registration is required — just create your connector files in the correct location.

Creating a New Source

Section titled “Creating a New Source”

For detailed step-by-step instructions on creating a new source, see Creating a New Source.

Architecture Concepts

Section titled “Architecture Concepts”

Architecture Concepts

Connector

Section titled “Connector”

The Connector class orchestrates the data transfer process. It requires three components:

  1. Config — configuration parameters and validation
  2. Source — data fetching logic
  3. Storage — data persistence (optional, can be null)

Key responsibilities:

  • Validate configuration parameters
  • Calculate date ranges for incremental/backfill imports
  • Coordinate between Source and Storage
  • Handle status updates and logging
  • Implement retry logic for the entire import process

All connectors must extend AbstractConnector (in src/Core/AbstractConnector.js).

Source

Section titled “Source”

The Source class is responsible for fetching data from the external API. It must implement:

  • fetchData(startDate, endDate) — fetch data for a date range
  • isValidToRetry(error) — determine if an error is transient (optional)

Helper methods available:

  • urlFetchWithRetry(url, options) — HTTP fetch with automatic retry
  • calculateBackoff(attemptNumber) — exponential backoff calculation
  • getFieldsSchema() — return available fields for the data source

All sources must extend AbstractSource (in src/Core/AbstractSource.js).

Storage

Section titled “Storage”

The Storage class handles data persistence. It must implement:

  • saveData(data) — persist data to storage
  • areHeadersNeeded() — check if headers need to be created
  • addHeader(columns) — create table/sheet headers

All storages must extend AbstractStorage (in src/Core/AbstractStorage.js).

Config

Section titled “Config”

Configuration objects handle:

  • Parameter definition and validation
  • Status tracking (in_progress, done, error)
  • Logging and error handling
  • State persistence (LastRequestedDate, LastImportDate)

Configuration classes extend AbstractConfig (in src/Core/AbstractConfig.js).

Section titled “Legal”

The @owox/connectors package is distributed under the MIT License. By submitting a contribution to this package, you affirm that you have the right to do so and that your work will be released under the same MIT License.

To clarify the intellectual property rights granted with each contribution, we also require a signed Contributor License Agreement (“CLA”) from every contributor. This protects you as the author, the OWOX team that stewards the project, and the community that depends on these connectors, ensuring everyone can rely on consistent MIT terms within this package.

For more details, review the full OWOX CLA.

Pull request authors must sign the OWOX CLA. The signing link appears automatically once you open a PR. If you cannot sign the CLA (for example, due to employment restrictions), do not submit a PR. Instead, please open an issue so that someone else can help.

Questions

Section titled “Questions”

Got a question? Feel free to ask the community:
