Google Sheets

Google Sheets is a cloud-based spreadsheet application that allows users to create, edit, and collaborate on spreadsheets in real-time.
Configure Google Sheets as a Destination in OWOX Data Marts to enable business users to access and analyze data directly within their spreadsheets.

Configuration Steps

Google Cloud Console

1. Enable the Google Sheets API

To allow OWOX Data Marts to interact with Google Sheets, enable the Google Sheets API in your Google Cloud project.

Sign in to your Google account and open the Google Sheets API page.
Click Enable to activate the API for your project.
If it’s already enabled, you’ll see the API dashboard — that’s fine.

2. Create a Service Account and JSON Key

A service account is required to authenticate OWOX Data Marts with Google Sheets.

Navigate to IAM & Admin > Service Accounts in the Google Cloud Console.
Create a new service account or select an existing one.
On the Service Accounts page, find the service account to use in OWOX Data Marts and click the Actions menu (three dots).
Select Manage keys, then click Add Key > Create new key.
Choose JSON and click Create.
Download the JSON key file.

OWOX Data Marts

1. Access the Destinations Page

In the OWOX Data Marts web application, navigate to Destinations from the main navigation pane and click + New Destination.

2. Choose Destination Type

Select Google Sheets from the Destination Type dropdown.

3. Set Configuration Details

Title: Provide a unique name for this Destination (e.g., “Marketing Reports”).

4. Choose Authentication Method

OWOX Data Marts supports two authentication methods for Google Sheets:

Option A: Service Account (JSON Key)

Paste the JSON key file from your Service Account into the Service Account JSON field. This method is recommended for automated, unattended workflows.

Option B: Google OAuth

Click Connect Google Account to authenticate using your personal Google account via OAuth. You will be redirected to Google’s consent screen to grant access. Once authorized, your account will be linked to this Destination.

Note: OAuth tokens are automatically refreshed. If your session expires or access is revoked, you can reconnect at any time by clicking Connect Google Account again.

5. Finalize Setup

Review your entries and click Save to integrate the Destination, or Cancel to discard changes.

Working with Imported Data

OWOX Data Marts owns only the columns it writes — the imported range — and treats the rest of your sheet as your space. This section describes what survives a refresh, what changes, and how the sheet reacts to schema or result-set changes.

What gets overwritten on every refresh

The imported rectangle — every cell from row 1 down to the last data row, across columns that came from the data mart — is fully owned by OWOX and rewritten from scratch on each refresh. Practical consequences:

Headers in row 1 are rewritten to the latest column names (or their aliases). Manual edits to header cells inside the imported columns will not persist.
Data cells inside imported columns are replaced by the values from the latest run. If you type a note or a formula directly into one of the imported columns, it disappears on the next refresh — even when SQL returns NULL for that cell. To keep your own content alongside the data, place it in columns to the right of the imported range (see What survives a refresh below).
Cells in the imported columns below the last data row are cleared. When a refresh produces fewer rows than the previous one — for example, after you apply a row limit or a filter — the leftover rows from the earlier run are wiped, so the user never sees stale numbers under fresh ones.

What survives a refresh

Cells and formulas to the right of the imported range — currency conversions, VLOOKUP enrichments, summary cells, and any other content placed in columns past the last imported one are kept intact across refreshes.
Auto fill-down for row-2 formulas. A formula placed in row 2 of any user column to the right of the imported range is automatically extended down to every data row on the next refresh. Relative cell references are shifted the same way Google Sheets shifts them when you drag the fill-handle. This is enabled by default — no settings to configure.
Static values in user columns are not overwritten by fill-down. Auto fill-down only acts on columns where row 2 actually holds a formula. If row 2 of a column to the right of the imported range is empty or holds a static value, that column is skipped entirely — so lookup tables, notes, or any other static content placed in those columns survives untouched.
Your column ordering. If you rearrange columns in row 1 by dragging headers in Google Sheets, OWOX remembers the new order on the next refresh and writes data rows in your layout. Re-ordering columns in the SQL source after the first run does not override your layout — your row 1 wins.
Pivot tables, charts, and named ranges that reference the imported range keep working. OWOX uses Sheets’ native column insert and delete operations, so dependent ranges, charts and pivot sources are updated automatically — the same as when you manually insert or delete a column.
Output Schema aliases. When you set a display alias for a column in the data mart, the alias appears in row 1 of the destination sheet without inserting or deleting any columns and without touching your other content.

How schema and result-set changes are reflected

A new SQL column is appended at the right edge of the imported range. Any user content in columns to the right shifts right by one. The new column starts empty until OWOX fills it with values from the SQL — it does not inherit any formulas or formatting from the column to its left.
A removed SQL column is deleted from the imported range. User formulas that referenced the removed column become #REF! — an honest signal that the column they depended on is gone.
Renaming a column in SQL is treated as removing the old column and adding a new one. Formulas that pointed at the old name become #REF! and need to be repointed to the new column.
A smaller result set (for example, when you set a Report row limit or apply filters that drop rows) only shows the rows produced by the latest run. Rows from a previous, larger refresh are cleared from the imported columns; user content in cells to the right of the imported range is left untouched.

Note: OWOX matches columns by their SQL name, not by position. Display aliases are presentation-only and do not affect this matching.

When a refresh fails

If a refresh fails before any data is delivered — for example, a warehouse connection error or a SQL error caught at execution — the destination sheet is left exactly as it was before the run. No headers are rewritten, no rows are cleared, and your last successful refresh stays visible until the next successful run replaces it.

Per-column header notes

Each imported column header carries a note (hover the cell in Google Sheets to view it). The note begins with the column’s Output Schema description (if one is set) followed by a provenance block: the data mart name, a link to it in OWOX Data Marts, and the timestamp of the latest refresh. Use these notes to confirm the source and freshness of any column at a glance.
